Fox 2.0 Performance Series IFP Smooth Body Shock for Jeep JL

Fox 2.0 Performance Series IFP Smooth Body Shock for Jeep JL

Description:

The 2.0 Performance Series Shocks delivers race-dominating performance in a hassle free bolt-on package. Their heat-reducing design includes a metal-impacted aluminum shock body that dissipates heat faster than conventional steel. Inside the Internal Floating Piston (IFP) separates shock oil from a high-pressure nitrogen gas chamber that provides a predicable ride quality capable of handling the roughest road conditions. Combine these new technologies with a competitive price for a winning combination.

Specifications:

  • Body - Aluminum shock body dissipates heat three times faster than steel.
  • Components - Black anodized 6061-T6 billet aluminum
  • Shaft - 5/8" hard chrome plated heat treated alloy steel
  • Piston - Race-developed high-flow piston design
  • Valving - Application specific valving to maximize offroad performance
  • Seals - Redundant sealing pack system main seal, wiper seal, scraper seal
  • Oil - Specially formulated for ultimate performance at variable temperatures
  • Reservoir - Internal reservoir design separates shock oil from the high-pressure nitrogen
  • Mounting - Applications available for stock and aftermarket lifts kits

Adjustments:

  • Nitrogen pressure
  • Compression valving
  • Rebound valving
Part # Lift Extended Length Collapsed Length Droop Over Stock Bump Stop Spacer Required Travel Position
985-24-171 0-1.5" 25.85 16.25 1.975 0" 9.6 Front
985-24-177 2-3" 26.35 16.75 2.475 At Least 1" 9.6 Front
985-24-179 3.5-4" 28.45 17.85 4.575 At Least 2" 10.6 Front
985-24-181 4.5-6" 30.05 18.45 6.175 At Least 3" 11.6 Front
Part # Lift Extended Length Collapsed Length Droop Over Stock Bump Stop Spacer Required Travel Position
985-24-172 0-1.5" 26.85 16.75 0.85 0" 10.1 Rear
985-24-178 2-3" 29.55 18.45 3.55 At Least 1" 11.1 Rear
985-24-180 3.5-4" 30.55 18.95 4.55 At Least 2" 11.6 Rear
985-24-182 4.5-6" 31.75 19.65 5.75 At Least 3" 12.1 Rear


Select Part #
From $68.98

Original: $229.95

-70%
Fox 2.0 Performance Series IFP Smooth Body Shock for Jeep JLā€”

$229.95

$68.98

Product Information

Shipping & Returns

Description

Description:

The 2.0 Performance Series Shocks delivers race-dominating performance in a hassle free bolt-on package. Their heat-reducing design includes a metal-impacted aluminum shock body that dissipates heat faster than conventional steel. Inside the Internal Floating Piston (IFP) separates shock oil from a high-pressure nitrogen gas chamber that provides a predicable ride quality capable of handling the roughest road conditions. Combine these new technologies with a competitive price for a winning combination.

Specifications:

  • Body - Aluminum shock body dissipates heat three times faster than steel.
  • Components - Black anodized 6061-T6 billet aluminum
  • Shaft - 5/8" hard chrome plated heat treated alloy steel
  • Piston - Race-developed high-flow piston design
  • Valving - Application specific valving to maximize offroad performance
  • Seals - Redundant sealing pack system main seal, wiper seal, scraper seal
  • Oil - Specially formulated for ultimate performance at variable temperatures
  • Reservoir - Internal reservoir design separates shock oil from the high-pressure nitrogen
  • Mounting - Applications available for stock and aftermarket lifts kits

Adjustments:

  • Nitrogen pressure
  • Compression valving
  • Rebound valving
Part # Lift Extended Length Collapsed Length Droop Over Stock Bump Stop Spacer Required Travel Position
985-24-171 0-1.5" 25.85 16.25 1.975 0" 9.6 Front
985-24-177 2-3" 26.35 16.75 2.475 At Least 1" 9.6 Front
985-24-179 3.5-4" 28.45 17.85 4.575 At Least 2" 10.6 Front
985-24-181 4.5-6" 30.05 18.45 6.175 At Least 3" 11.6 Front
Part # Lift Extended Length Collapsed Length Droop Over Stock Bump Stop Spacer Required Travel Position
985-24-172 0-1.5" 26.85 16.75 0.85 0" 10.1 Rear
985-24-178 2-3" 29.55 18.45 3.55 At Least 1" 11.1 Rear
985-24-180 3.5-4" 30.55 18.95 4.55 At Least 2" 11.6 Rear
985-24-182 4.5-6" 31.75 19.65 5.75 At Least 3" 12.1 Rear
